FRAME
Spark RC Carbon HMF, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 34 SC Float Performance Air Grip, 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer, Reb. Adj. / Lockout / 120mm travel
REAR SHOCK
FOX NUDE 5 EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, DPS / Reb. Adj. / Travel 120-80-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, 3 Suspension modes
REAR DERAILLEUR
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
SHIFTERS
Shimano XT SL-M8100-IR / Rapidfire Plus, Ispec EV clamp
CRANKSET
Shimano XT FC-M8120-1 / Hollowtech 2, 32T
BB-SET
Shimano SM-BB71-41A / shell 41x92mm
CHAIN
Shimano SLX CN-M7100
CASSETTE
Shimano SLX CS-M7100-12 / 10-51 T
BRAKES
Shimano XT M8100 Disc
ROTOR
Shimano SM-RT66 / 6 Bolt / 180/F and 160/R
HANDLEBAR
Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar / 8° / 740mm, Syncros Performance XC lock-on grips
H'STEM
Syncros XC 2.0, Syncros Cable Integration System, -12° rise / 6061 Alloy / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan 2.0 / 10mm offset, 31.6x400mm
SEAT
Syncros Belcarra Regular 2.0, CRMO rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton 2.5-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim / 28H / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Maxxis Rekon Race / 29x2.4" / 60TPI Foldable Bead, Tubeless Ready / EXO
REAR TIRE
Maxxis Rekon Race / 29x2.4" / 60TPI Foldable Bead, Tubeless Ready / EXO
ACCESSORIES
Transport Axle
APPROX WEIGHTS IN KG
11.7 (Tubeless setup)
APPROX WEIGHTS IN LBS
25.79 (Tubeless setup)
MAX. SYSTEM WEIGHT
128kg
