FRAME
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 36 Float Rhythm Air Grip, 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 160mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology. Suspension & Dropper Remote. 3 Suspension modes
REAR DERAILLEUR
Shimano XT RD-M8100 SGS. Shadow Plus / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
CRANKSET
Shimano SLX FC-M7120-1 / Hollowtech 2, 55mm CL / 32T
CHAINGUIDE
SCOTT custom
BB-SET
Shimano BB-MT500 / shell 41x92mm
CHAIN
Shimano Deore CN-M6100
CASSETTE
Shimano Deore CS-M6100-12 / 10-51 T
BRAKES
Shimano Deore M6120 4 Piston Disc
ROTOR
Shimano SM-RT64 CL / 203/F and 180/R
HANDLEBAR
Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
H'STEM
Syncros AM 1.5, Syncros Cable Integration System. 4° rise / 7050 Alloy / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
SEAT
Syncros Tofino 2.0 Regular, CRMO rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148M / 12x148mm
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
FRONT TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
REAR TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
EXTRAS
Syncros Fork Fender
APPROX WEIGHTS IN KG
14.8 (Tubeless setup)
APPROX WEIGHTS IN LBS
32.63 (Tubeless setup)
MAX. SYSTEM WEIGHT
128kg
