Frame
: Toray UD carbon race chassis optimising 24T/40T/3K fibre mix / 37mm main pivot bearings / 28mm linkage bearings / UD carbon linkage / signature TRL suspension design / custom headtube with adjustable front centre plus-minus 5mm / internal cable routing / integrated fork bump-stops / 12 x 150mm rear axle / 203mm travel / Fox Van RC Performance / LSC / rebound adjust
Forks
: Rockshox Boxxer RC / 203mm travel / coil spring / low speed compression / rebound adjust / 20x110 / Maxle Ultimate DH
Rear Derailleur
: Shimano Zee M640 Shadow Plus
Front Derailleur
: Gamut P30s
Shifters
: Shimano Zee M640 Rapidfire Plus 1x10 speed
Chainset
: Shimano Zee M645 36T 165mm
Bottom Bracket
: Shimano SM-BB52
Chain
: Shimano HG54
Freewheel/Cassette
: Shimano HG500 10 speed cassette 11-25T
Headset
: Saracen off-set headset / 0mm
Stem
: Kore Torsion V2 / 50mm / direct mount / 0 degree rise / 31.8mm clamp
Handlebars
: Kore Torsion riser bar / 800mm wide / 20mm rise / 5 degree up bend / 7 degree back bend
Brakes
: Shimano M640 203/203mm
Rims
: Kore Torsion SL 27.5 32h
Front Hub
: Formula DHL-92 sealed bearing 32h front / Novatec DH12SB-SS sealed bearing 32h rear
Rear Hub
: Formula DHL-92 sealed bearing 32h front / Novatec DH12SB-SS sealed bearing 32h rear
Spokes
: Double-butted stainless steel
Tyres
: Maxxis Highroller II / 42a Super Tacky / 27.5 x 2.4"
Saddle
: Kore Fazer EX
Seatpost
: Kore Torsion / 30.9mm
Pedals
: Alloy MTB / sealed bearings / replaceable pins
Grips
: Saracen lock-on grip
